AIIIBV compounds

BondaTek provides¬† Ge, GaAs, GaP, GaN, GaSb, InP, InAs, InSb wafers to micro- electronics and optoelectronics industry in diameter range from 2" to 4" with orientation<100> or <111>,¬† EPD< 5000 cm-2 and epi ready surface.

BondaTek also supplies epitaxy-based( GaAs and InP based) compound semiconductor epi-wafers.

GaAs based

  • PHEMT (InGaP- or AlAs- Etch Stop, E- Mode)
  • MHEMT



InP based

  • HBT (DHBT, SHBT, C- or Be- Base doped)
  • MHEMT
  • RTT, RTD

MATERIALS

  • Semiconductor Si wafers and Solar wafers
  • Silicon on insulator (SOI) wafers
  • Mask blanks (soda lime and quartz)
  • Glass wafers (Pyrex 7740, quartz, soda lime, etc)
  • AIIIBV compounds (GaAs, GaP, InP, InAs, etc)
  • Sapphire wafers
  • Sputtering targets
  • Thin films-Oxide, nitride
  • Packing boxes for crystal, wafers, filter, chip, etc
  • Optical component

SERVICES

  • Fabrication of soda lime/quartz photolithographic masks
  • Silicon microfabrication (wet etching, dry etching and wafer bonding)
  • Consultancy of fabrication process
  • Characterization of microdevices/microsystems
  • Consultancy of microfluidics and biological microdevices
